Minimum Order Quantity: 1
Price: 5
Model NO.: |
LSQ-TG (ISO A STEEL) |
Working Pressure: |
3000 Psi |
Body Size: |
3/4, 1 |
Rated Flow: |
28 GPM, 50 GPM |
Temperature Range: |
-20ºC To +120ºC |
Seal Material: |
NBR |
ISO Standard: |
ISO 7241-1 Series A |
Poppet Valve: |
Yes |
Ball-locking Mechanism: |
Yes |
Material: |
Steel |
Socket Material: |
Solid Bar Stock |
Hex Size 1: |
S38, S44.5 |
Hex Size 2: |
S35, S41 |
Thread Type: |
G3/4 NPT3/4, G1" NPT1" |
Production Capacity: |
100000 Set/Month |
Model NO.: |
LSQ-TG (ISO A STEEL) |
Working Pressure: |
3000 Psi |
Body Size: |
3/4, 1 |
Rated Flow: |
28 GPM, 50 GPM |
Temperature Range: |
-20ºC To +120ºC |
Seal Material: |
NBR |
ISO Standard: |
ISO 7241-1 Series A |
Poppet Valve: |
Yes |
Ball-locking Mechanism: |
Yes |
Material: |
Steel |
Socket Material: |
Solid Bar Stock |
Hex Size 1: |
S38, S44.5 |
Hex Size 2: |
S35, S41 |
Thread Type: |
G3/4 NPT3/4, G1" NPT1" |
Production Capacity: |
100000 Set/Month |
| Body Size (in) | 3/4 | 1 |
|---|---|---|
| Rated Pressure (PSI) | 3000 | 3000 |
| Rated Flow (GPM) | 28 | 50 |
| Temperature Range (std seals) | -20°C to +120°C | |
| Standard seal material | NBR (Nitrile) | |
| ISO | PARTNO. | LS | ¢D | HEX1 | A | T |
|---|---|---|---|---|---|---|
| 20 | LSQ-TG-06SF | 85 | 49 | S38 | 19 | G3/4 NPT3/4 |
| 25 | LSQ-TG-08SF | 98.5 | 57 | S44.5 | 23 | G1" NPT1" |
| ISO | PARTNO. | LP | d | C | HEX2 | A | T |
|---|---|---|---|---|---|---|---|
| 20 | LSQ-TG-06PF | 57 | 29 | 29 | S35 | 19 | G3/4 NPT3/4 |
| 25 | LSQ-TG-08PF | 65 | 34.3 | 34.3 | S41 | 23 | G1" NPT1" |
| ISO | PARTNO. | LP | D | HEX1 | HEX2 | T |
|---|---|---|---|---|---|---|
| 20 | LSQ-TG-06 | 115 | 49 | S38 | S35 | G3/4 NPT3/4 |
| 25 | LSQ-TG-08 | 130.5 | 57 | S44.5 | S41 | G1" NPT1" |
